Find your vehicle › Toyota › Hilux › Hilux 2015–2025
Long range fuel tanks
2 tanks fit the Hilux 2015–2025, listed with the most popular in Africa first.
TH15R1 · 150 litre steel replacement tank
Most popular in Africa
Swaps the factory tank for a 150 litre Brown Davis steel tank in the same place. The spare wheel stays where it is and nothing changes in the cab.
| Part number | TH15R1 |
| Tank type | Replacement |
| Material | Steel |
| Capacity | 150 L |
| Tank location | Replaces the factory tank |
| Filler point | Factory filler |
| Fuel supply | Factory system |
| Fitting time | 2 hours |
| Modifications | None required |
| Fitment notes | All 4WD diesel models, including 48V. |
Fuel and range: standard vs Brown Davis
+70 L
more fuel
+88%
more capacity
+583 km
extra range (approx.)
Standard figure is the factory capacity (80 L factory tank). Range assumes 12 L/100 km, typical for a loaded touring 4×4. Towing, sand and corrugations use more fuel. Never run a tank completely dry.
Molly Dixon
PT-TH15R1 · 145 litre poly replacement tank
A lighter moulded poly tank that holds 145 litres. A good choice for fleets and bakkies that mostly run on tar.
| Part number | PT-TH15R1 |
| Tank type | Replacement (poly) |
| Material | Poly |
| Capacity | 145 L |
| Tank location | Replaces the factory tank |
| Filler point | Factory filler |
| Fuel supply | Factory system |
| Fitting time | 2 hours |
| Modifications | None required |
| Fitment notes | 4WD diesel models only. |
Fuel and range: standard vs Brown Davis
+65 L
more fuel
+81%
more capacity
+542 km
extra range (approx.)
Standard figure is the factory capacity (80 L factory tank). Range assumes 12 L/100 km, typical for a loaded touring 4×4. Towing, sand and corrugations use more fuel. Never run a tank completely dry.
Under vehicle protection
UGTH15 · UG2 four-piece guard set
Our UG2 four-piece set in 3 mm steel, covering the whole underside from the steering to the 4WD actuator.
| Part number | UGTH15 |
| Guard type | 4 pieces |
| Protects | Steering, front, sump, transmission, transfer case and 4WD actuator |
| Material | 3 mm steel, powder coated grey |
| Fitting time | 1 hour |
Floor mats
FM-TH15F · Front floor mats
Driver and passenger mats. Automatic models only.
FM-TH15S · Full set of floor mats
Front and rear mats for the double cab. Automatic models only. The rear mats do not suit 48V models.
Questions
Does the kit include everything I need?
Yes. Every Brown Davis tank comes with the brackets, hoses, fittings and step-by-step instructions. Auxiliary tanks also include the pump or changeover wiring and a gauge.
Will my fuel gauge still work?
Replacement tanks use the factory sender, so your gauge keeps working. Auxiliary tanks come with their own gauge.
Why is the distance-to-empty reading wrong?
The vehicle’s computer still thinks it has the factory tank size, so the distance-to-empty figure will read low. Use the fuel gauge and your trip meter instead.
Does it change my ground clearance?
No. Our tanks follow the factory lines and keep your ramp-over and departure angles.
